Intelligent Passenger Medical Hospital Elevator

Hospital lifts may be preferred as semi-auto, full auto or hydraulic. Important! Hospital Elevators should be overhauled by periodical and general elevator maintenances that authorized elevator maintenance firms make. Hosptial Elevator is not onlyused to convey the passengers.It has been put with the special and strict requirements because of its special use,function and performance.

SUNNY Hospital Elevator Description

1. The hospital elevator lift are designed for different types of residential buildings, villas residential, office buildings. 2. hospital elevator lift have high performance elevator parts, permanent magnet synchronous drive and intelligent door system, safe and reliable. 3. hospital elevator lift permanent magnet synchronous traction machine,smaller volume but higher efficiency, saving more space for the headroom. 4. hospital elevator lift highest safty standard, to ensure passenger safty. 5. hospital elevator multiple customized for the transportation arrangement and structure for matching the design style .

SUNNY Hospital Elevator Specification

Model	Patient Bed Elevator Lift
Application	Residential,Hotel,Office
Loading(Kg)	630	800	1000	1350	1600
Speed(m/s)	1.0/1.75	1.0/1.75/2.0	1.0/1.75/2.0	1.0/1.75/2.0/2.5	1.0/1.75/2.0/2.5
Motor	Gearless Motor
Door Control	VVVF
Opening Width(m)	800*2100	800*2100	900*2100	1100*2100	1100*2100
Headroom(m)	4.0-4.5
Pit Depth (m)	1.5	1.5-1.7	1.5-1.8	1.8-2.0	1.8-2.0
Total Height(m)	<150m
Stop	<56
Brake voltage	DC110V
Power	380V,220V,50HZ/60HZ

About SUNNY Elevator

SUNNY Elevator is always engaged in researching into, developing, manufacturing various building traffic and transport systems such as elevator, escalator, moving walk etc. Through the centurial trials and hardships, SUNNY Elevator never changes its advanced technology.

SUNNY Elevators safely operate in all kinds of high grade buildings in over 100 countries and regions. As time flies, it continues the rigorous and conscientious spirits of the German nation. SUNNY Elevator popular-fixes the most superb elevators and escalators all aver the world and opens the gate of the artistic elevator palace.

FAQ

1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
